Himore 308418003 2600 PSI 2.4 GPM 7/8" Horizontal Shaft Pressure Washer Pump Replacement Kit - Compatible with Most Gas Pressure Washers, Ideal for Home Cleaning, Car Washing, and Outdoor Surface Maintenance
Free shipping on all orders over $50
7-15 days international
15 people viewing this product right now!
30-day free returns
Secure checkout
52484006
Description
Previous page Next page Previous page Next page 1 Pressure Washer Pumps 2 Pumps & Spray Kits 3 Guns, Wands & Nozzles 4 Parts & Accessories Pressure Washer Pumps Model RMW22G24-EZ-SX Add to Cart Model 308653052 Add to Cart Model 308418003 Add to Cart Model 308653035 Add to Cart Model 308653071 Add to Cart Model CP3625 Add to Cart Customer Reviews 5.0 out of 5 stars 1 5.0 out of 5 stars 1 — — — — Price $139.99$139.99 $84.99$84.99 $104.99$104.99 $99.99$99.99 $84.99$84.99 $199.99$199.99 Manufacturer Annovi Reverberi Himore Himore Himore Himore Himore Shaft 7/8" 7/8" 7/8" 7/8" 3/4" 3/4" Gallons per Minute 2.2 2.3 2.5 2.5 2.5 2.5 Max PSI/Min PSI 2400/2200 2800/2600 2600/2400 3100/2900 3000/2800 3600/3200 Orientation Vertical Vertical Horizontal Vertical Versatile Horizontal Are pressure washer pumps interchangeable? Many pumps are. However, compatible replacement options do vary depending on your pressure washer’s engine shaft diameter & engine orientation, the original pump’s bolt pattern, and your engine's horsepower. What pump do I need if my shaft has a spline/gear instead of a keyway? Your original pump was likely a strap-style (or bow tie) pump. That style isn’t made anymore. However, you can remove the spline and use your model number to find a replacement pump that you’ll install directly onto the shaft with a keyway. Do I need a keyway for installation, and do your pumps come with one? Our pumps do require a keyway for installation onto the engine shaft. If a keyway is pictured in the listing, it will come with one. If you need to purchase one separately, you can do so from our catalog. Do I need to change the oil in my pump? Many of our pumps don’t require oil maintenance, but some models do need oil changes. Generally, pumps with an oil vent port will need regular oil changes. Pumps without that port are sealed units and don’t need oil changes.
Features
The ROP Shop replacement Horizontal Pressure Washer Pump Kit
Specs - Keyway - Overall Dimensions 3/16" x 1/4" x 1 1/8". Quick Connect - Male Pipe Thread 3/8". Coupler End 3/8". Max PSI 4200. Pump - Max PSI 2600. Max Flow 2.4 GPM. Max RPM 3400. Shaft Diameter 7/8" Hollow Short Shaft. Bolt Pattern 2 5/8" (Center to Center) & 1 7/8" (Center to Each Outer Hole). Max HP 6.5. Inlet Connection Type Standard Garden Hose. Outlet Tube Connection 22mm Male. Oil Capacity 75 mls (2.5 oz). Refer to images 2 & 3 for more information
Includes - (1) Horizontal Pressure Washer Pump with Chemical Injector, Unloader Valve, Thermal Release Valve, Outlet Tube (all come pre-installed), Oil Cap, (1) Keyway, (1) Hose, (1) 3/8" MPT Quick-Connect Socket, (4) Hex Bolts & (4) Washers; comes as shown in the first image
COMPATIBLE Replacement pump for ▪ Himore 308418003 ▪ Honda Excell XR2500, XR2600, XC2600, EXHA2425, XR2625 ▪ Monsoon XR2500, XR2600, XC2600, EXHA2425, XR2625 & more. Also compatible with Honda GC160 engines with 7/8" shaft diameter.
This pump mounts horizontal (oil cap points up). Uses 75 mls (2.5 oz) of 85W-90 gear oil. Has a sight glass to view oil level and a drain plug for a simplified oil changing process. Pump needs at least 5HP to handle PSI. Pump head cannot be flipped. Brass outlet tube MUST be removed to use quick-connect. Please note it is not recommended to run any pressure washer pump above its MAX PSI rating. Doing so can result in damage to the pump (not covered by warranty) and/or serious bodily injury
